Durable Wall Box EV Charger Commercial EV Charger 22kw Double Gun Type1 Arrival
EV Charger Factory Manufacturer OCPP Type 2 32A 3 Phase 7kw 22kw Wallbox AC Fast Electric Charging Station EV Car Charger With Wifi App Control RS485
-- Electric ev car charger with type 1 type 2 plug to charge cars.(TESLA needs a adapter.)
-- Screens show ev car charger electricity consumption, current, voltage, hours etc.
-- Managing system for adjusting current, observing charging data and history etc.
-- Build in type B RCD leakage protection: detect all leakages from cars.
-- App control start and stop ev cars charging, make appointment for charging.
-- Self adjustable power to coordinate with ev cars' obc power.
-- customize logo, language, manual, RFID card for ev chargers.
3-Phase AC Floor -mounted Integrated Charger station for Electric Vehicle charging
Lekol Floor-mounted integrated charging station features:
* Charging plug meet IEC62196-2 2010 SHEET 2-IIe standard.
* Product assembly meet IEC 61851-1 2010 charging mode 3 connection method B2.
* Nice appearance, hand-held ergonomic design,easy plug.
* Reliability of materials, Anti flaming, Pressure-resistant, Abrasion resistance, Impact resistance and high oil.
* Excellent protection performance, protection grade IP55(outdoor)
* Function: WiFi, APP, CAN/Customized
Applications:
This product integrates charger, charging interface, human-computer interaction interface, communication, billing, etc., for the rapid charging of electric vehicles. Its use of small area, fast charging time and other characteristics,generally used in various large charging stations, shopping malls, office buildings and other "instant charge" places.
Specification
| Input & Output |
| Input Voltage | 3-phase, 400V±10% | Output Current | 16A/32A |
| Input Frequency | 50/60HZ | Output Power | 11kW/22kW |
| Charging Interface Type | IEC 62196-2/SAE J1772 | | |
| Function & Accessory |
| Charging Control | "Plug and Play" or "Card Control" | LED Indicator Light | Power:Red Charging:Green Fault: Red Connect:Green |
| LCD Screen | 4.3 inch color display | RCD | Type A |
| Safety Protection |
| Surge Protection | Yes | Over Temperature | Yes |
| Leakage | Yes | Over/Under Voltage | Yes |
| Over Current | Yes | Ground Protection | Yes |
| Runtime Environment |
| Protection Degree | IP 54 (Outdoor) | Attitude | ≤2000 meters |
| Environment Temperature | -30℃ ~ +50℃ | Cooling | Natural Air Cooling |
| Relative humidity | 0-95% non-condensing | | |
| Package |
| Enclosure Material | Aluminum Alloy | Dimension(W/D/H) | 200/100/1400mm |
| Charging Adapter Cable | 5 meters or Optional | Weight | ＜10kg |
FAQ
| What is your terms of payment? |
| A: West Union fast payment, T/T |
| Do you test all your chargers before shipping? |
| A: All major components are tested before assembly and each charger is fully tested before shipped |
| Can I order some samples? How long? |
| A: Yes, and usually 7-10 days to production and 7-10 days to express. |
| How long to fully charge a car? |
| A: To know how long to charge a car, you need to know the OBC(on board charger) power of the car, the car battery capacity, the charger power. The hours to fully charge a car =battery kw.h/obc or charger power the lower one. For e.g, the battery is 40kw.h, obc is 7kw, charger is 22kw, the 40/7=5.7hours. If the obc is 22kw, then 40/22=1.8hours. |
| Are you Trading Company or manufacturer? |
| A: We are professional EV charger manufacturer. |
